Series and Parallel
PHY 100 & 103
Lab PDFPhysical lab for online 103 course.
Equipment
| Name | Location | Quantity |
| Cables, Banana, Black | JE-105,107,109,113 | 4 per table |
| Cables, Banana, Red | JE-105,107,109,113 | 4 per table |
| Clips, Alligator | JE-105A-S58 | 10 per table |
| Multimeter, Digital, Extech EX420 - Battery | JE-105A-D103 | 1 per table |
| Multimeter, Digital, Sperry DM5300 - Battery | JE-105A- D101 | 1 per table |
| Power Supply, Extech (Model #382213) | JE-105A-X12/13 | 1 per table |
Notes
Also add three 10 ohm resistors per table.
